Decorative Lighting Dimmable DMX 5050 120V LED Strip

Basic Information
Place of Origin: China
Brand Name: filamentlux
Certification: CE,ROHS,
Model Number: FML-001
Minimum Order Quantity: 3000PCS
Price: USD0.32-USD0.52
Packaging Details: Color box or Blister
Delivery Time: 20-25days
Payment Terms: T/T or L/C
Supply Ability: 500kpcs per month
Detail Information
Application: Decorative Lighting Lamp Luminous Flux(lm): 500LM/M
Lamp Body Material: PVC,PCB,Copper Wire Emitting Color: Warm Light /White Light/Blue/Red/Yellow/RGB/Changeable/Green/Others
LED Light Source: SMD2835 LED Chip Product Name:: Led Light Strips
LED Quantity: 120leds/m IP Rating: IP65
CRI: ≥80,90 PCB Width: 12mm
High Light:

12mm 120V LED Strip

,

5050 120v dimmable led strip lights

,

5050 120v led tape light


Product Description

Decorative Lighting Dimmable DMX 5050 120V LED Strip



High quality, low power consumption, energy efficiency. High flexibility, waterproof, and all sorts of stylish design. OEM/ODM services are available. More than 50,000 hours long lifespan with 1-3 years warranty. Wide range of emitting colors and applications. Can be cut as your actual demand and reduce waste. 3M adhesive tape on backside, easy to install. Certifications: RoHS and CE approved, etc.

  • Widely used for home decoration use, hotels, clubs, shopping malls
  • Architectural decorative lighting, boutique atmosphere lighting
  • Extensively applied in Backlighting, concealed lighting, channel letter lighting
  • Emergency & security lighting, advertisement sign lighting
  • Decorative lights for holiday, event, show exhibition
  • Applicable for automobile and bicycle decoration, border or contour lighting

120V AC LED STRIP LIGHT Parameters:

ITEM NO. FML-HV-5730-120SH
INPUT VOLTAGE 120V
Lamp Power 14.4W/M 7-9w/m 10W/M
LED QTY 30led/m 60LED/m 120led/m
IP Rank IP20/IP50/IP65/IP66/IP67/IP68
FREQUENCY 50Hz
LED type SMD2835 SMD5050
RATED POWER 7.5W±10%/m
PF >0.9
Luminous Flux ≥500LM 500LM/M 412LM/m 522lm/m
LPW ≥70lm/W
CCT 2800-3200k, 4000-4500K, 6000-6500K, 2700k 3000k, 4000k, 6500k
Ra ≥70
SDCM <7 SDCM
Working condition -10℃~40℃;10%~90%
Insulate class II
Install method Clip
Driver connection Plug in-off
Dimmer /
Cover/color /
NET weight(100m) 11kg
Product size L100000mm×W14.5mm×H7mm
Inner box /
Master carton 330mm × 330mm ×210mm
Packing 100m/CTN
Lifetime 25000h
Warranty 1 year



120V AC LED STRIP LIGHT Quick Details:

  • Lamp Power: 8W
  • Lamp Luminous Flux(lm): 500LM/M
  • Working Lifetime(Hour): 30000
  • Lamp Body Material: PVC, PCB, Copper Wire
  • Certification: CCC, ce, CQC, EMC, ETL, LVD, PSE, RoHS, SASO, VDE
  • Model Number: FML-HV-2835-120-N
  • Warranty(Year): 1/2 years
  • Emitting Color: Warm Light /White Light/Blue/Red/Yellow/RGB/Changeable/Green/Others
  • LED Light Source: SMD2835 LED Chip
  • Product Name: Led Light Strips
  • LED Quantity: 120leds/m
  • IP Rating: IP65
  • CRI: ≥80,90
  • PCB Width: 12mm
  • Input Voltage(V): AC120V



1) Pay attention +/- when SMT

2) LED SMT need to be tidy and without weak soldering

3) Smooth soldering point and clean LED

4) No any scar in the PCB

5) Can not see any color and brightness difference when by naked eye

Decorative Lighting Dimmable  DMX 5050 120V LED Strip 0

Decorative Lighting Dimmable  DMX 5050 120V LED Strip 1

Decorative Lighting Dimmable  DMX 5050 120V LED Strip 2

Decorative Lighting Dimmable  DMX 5050 120V LED Strip 3

Decorative Lighting Dimmable  DMX 5050 120V LED Strip 4
