| Place of Origin: | China |
|---|---|
| Brand Name: | filamentlux |
| Certification: | CCC, CE, CQC, EMC, ETL, LVD, PSE, RoHS, SASO, VDE |
| Model Number: | FML-001 |
| Minimum Order Quantity: | 3000PCS |
| Price: | USD0.32-USD0.52 |
| Packaging Details: | Color box or Blister |
| Delivery Time: | 20-25days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 500kpcs per month |
| Model Number: | FML-12V-COB-320 | Power: | 8W 10W |
|---|---|---|---|
| CCT: | 2200k 2800k 3000K 4000K 6000K 2700K 6500K | Watt: | 8W/m 12W/m 14W/M |
| Lamp Body Material: | PVC,PCB,Copper Wire | Certification: | CCC, CE, CQC, EMC, ETL, LVD, PSE, RoHS, SASO, VDE |
| Warranty(Year): | 1/2 Years | Emitting Color: | Warm Light /White Light/Blue/Red/Yellow/RGB/Changeable/Green/Others |
| LED Light Source: | SMD2835 LED Chip | Product Name:: | Led Light Strips |
| LED Quantity: | 224 Or 384 Or 528 LEDs/m | IP Rating: | IP20/IP66/IP67 |
| CRI: | ≥90 | PCB Width: | 12mm |
| Input Voltage(V): | 12V | ||
| High Light: | IP20 COB LED Strip,2200k COB LED Strip,224LEDs/m 12v strip light |
||
LED STRIP LIGHT 12V COB 320PCS/m IP20
1. High-Quality Chip→ Ideal for LED lighting application to avoid multi-shadows.
2. Higher heat conductivity for better thermal management.
3. Provide variable and innovative array LED layout designs and combinations.
4. Professional Jewelry and cosmetics Led Lighting application.
5. 50000 hours life span.
12V COB LED STRIP LIGHT Quick Details:
12V AC LED STRIP LIGHT Parameters:
| ITEM NO. | FML-12V-COB-320 |
| Power | 10W/12W |
| INPUT VOLTAGE | 12V |
| CCT | 2200k 2800k 3000K 4000K 6000K 2700K 6500K |
| Watt | 8W/m 12W/m 14W/M |
| FREQUENCY | 50Hz |
| LED QTY | 224 or 384 or 528 LEDs/m |
| RATED POWER | 10W±10%/m |
| PF | >0.9 |
| Luminous Flux | ≥700LM |
| LPW | ≥90lm/W |
| CCT | 2800-3200k,4000-4500K,6000-6500K |
| Ra | ≥70 |
| SDCM | ＜7 SDCM |
| Working condition | -10℃～40℃；10%～90% |
| Insulate class | II |
| Install method | Clip |
| Driver connection | Plug in-off |
| NET weight(100m) | 12kg |
| Product size | L100000mm×W16.5mm×H6.5mm |
| Master carton | 330mm × 330mm ×210mm |
| Packing | 100m/CTN |
| Lifetime | 25000h |
| Warranty | 2 YEAR |
| PCB Width | 8mm/10mm |
| IP Rating | IP20/IP65/IP67/IP68 |
| Switch Mode | Bluetooth, Remote Control, Manual Button |
Wide applicability, easy to install and maintain; Extremely luminous, with wide viewing angle; PCBase board, unique waterproof technique; Energy saving and environmental conservation, long lifespan; Operation low voltage (DC24V) for human safety, various colors available.
3 Years Warranty.
| Model | Watt | Width | Working Voltage | RA | How to Cut |
| 224 LEDs/m | 8W/m | 8mm | 12V/ 24V | >90 | 7.15cm / cut |
| 384 LEDs/m | 12W/m | 5mm / 8mm | 5V/ 12V/ 24V | >90 | 4.15cm / cut |
| 528 LEDs/m | 14W/m | 10mm | 12V/ 24V | >90 | 4.5 cm/ cut |
This COB LED STRIP product can be used for :
1. Decorate shopping mall, super market
2. Club, store, hotel, restaurant, school, library, art gallery, museum, office
3. Large building, building exterior decoration
4. Window display lighting, mirror decoration, large scale backlight
5. Indoor and outdoor lighting and for festival decoration
Installation Instructions
1. Clean the surface you intend to stick the light strip to Peel off the backing strip off the adhesive tape
2. Press and hold the light strip firmly against the surface
3. Plug your light strip into a compatible 24V DC power supply or dimmer
4. Connect your power supply to a wall outlet Enjoy your beautiful LED light strip!
5. Our light strips are also cuttable and connectable with extension cables.
